DISC
GRINDERS
Manufacturers,
Exporters & Suppliers of all kinds of Disc
Grinders... |
| |
Buy original  products and not cheap imitations which are more expensive in the long run. |
| |
 |
Vertical
Disc Grinders |
|
|
|
Model - 648 Direct Drive
Manufactured by "Prem Brothers" Since 1959 |
"POWER
MASTER" Bench type Disc Grinders
are suitable for Edge Grinding,Radius Griniding
of components.
Disc Grinders are available in 0.5 HP Disc dia
8", 1.0 HP 10"/12", 2.0 HP 14" in different table sizes.
They have a Heavy duty direct drive Motor, Dynamically
Balanced Disc Plate, Tilting Table 45 down 15
up, Disc Guard for safety, Electricals : Rotary
Switch. Grinders also available with Standing/Sitting
height Pedestal on request. Wide range of Polishing,
Grinding machines & Dust collectors are
also available. |
| |
| |
| |
|
Technical Specifications |
Disc
Dia. |
HP |
Table
Size |
Apprz.
Weight Kg |
Over
all Dim in mm |
8" |
0.5
HP |
360
x 150 |
80 |
L
- 550
W - 410
H - 400 |
10" |
1.0
HP |
360
x 150 |
80 |
12" |
1.0
HP |
450
x 200 |
90 |
L
- 600
W - 510
H - 500 |
14" |
2.0
HP |
450
x 200 |
100 |
|
|
| |
|
Horizontal
Type Disc Grinder |
|
|
Model - 648-1-250
Manufactured by "Prem Brothers" Since 1959
|
Model
- 222-2-355 |
Features:
* Heavy Duty Direct Drive Motor
* Disc Guard for Safety
* Electricals: DOL Starter
* Dynamically Balanced Disc Plate
* Bench Type Configurations
* Machine for Standing height working
Technical Specifications
S.
No. |
Model |
Disc
Dia. |
HP |
RPM |
Electricals |
1 |
648-1-250 |
250 |
1.0 |
2800 |
DOL
Starter |
2 |
222-2-355 |
355 |
2.0 |
1440 |
DOL
Starter |
3 |
222-3-355 |
355 |
3.0 |
1440 |
DOL
Starter |
|
| Wide
range of Machines available to suit different job requirements |
| NOTE:
We reserve the right to change. |
| Due
to constant improvement, techincal specifications and
dimensions are subjects to modification without prior
notice. |
