"POWER
MASTER" Heavy Duty, Double Ended
Pedestal Grinding Machines are specially designed
to provide heavy Metal removal in Engineering
Workshops, Factories, Forging units, Foundries
etc. Each Pedestal Grinder is complete with
Electric Motor, Starter, Two Grinding Wheels,
Two M.S. Wheel Guards with exhaust outlets,
and two adjustable tool rests. The motor is
fitted in the base of the Pedestal Grinder and
the machine is equipped with 2 Speed V-Belt
Drive. Arrangement is provided for increasing
the spindle R.P.M when the Grinding Wheel Diameter
is reduced. This helps to maintain the correct
surface foot per minute Grinding speed.
Optional Accessories
* Eye Shields with Spark Arrestor
* Dust Collectors
* Drill Point Grinding Attachment
Technical Specifications
S.No |
Model |
H.P. |
RPM |
Wheel
Size
(DIA x WIDTH x BORE) |
1 |
PG-12 |
2.0 |
1950
/ 2200 |
300
x 40 x 31.75 |
2 |
PG-14 |
3.0 |
1750
/ 2050 |
350
x 50 x 38.10 |
3 |
PG-16 |
3.0 |
1500
/ 1750 |
400
x 50 x38.10 |
4 |
PG-18 |
5.0 |
1300 / 1500 |
450
x 50 x 38.10 |
5 |
PG-20 |
5.0 |
1200
/ 1300 |
500
x 75 x 38.10 |
6 |
PG-24 |
7.5 |
1000
/ 1200 |
600
x 75 x 203.2 |
|
products and not cheap imitations which are more expensive in the long run.
